Description:
Pelleting system for animal feed consists of a feeder, single or double conditioners and a pelleting machine.
Pellet mill is use for processing feeds for livestock, poultry, aqua, shrimp and fish, etc.
The pellet mill system is used to produce animal feed (sheep, pig, piglet, and cow) and poultry feed (chicken layer feed, broiler feed, duck feed, and other specialized poultry feed), aqua feed (shrimp, fish) and so on.
Features:
High efficiency on feed distribution
High capacity
Good quality of pellet
Better use: hydraulic system for die change and roller adjustment, quick and precise operation; auto-lubrication system and die & roller lifting device, saved labor; overload protection and door protection for human and machine safety.
Motor: Siemens, ABB and according to customer request or need.
Homogeneous conditioning which improves starch cooking, increase capacity and lower production cost
Stable feeding to ensure uniformity of material conditioning process and product qualityQuick-release design reduces down-time for replacing dies and rollersTwo rollers with eccentric roller shaft design
Rotation speed control with V-belt drive train from the motor to driven wheel
Die speed varies from 4.5 to 8.5 m/s depend on the pellet formula
Sturdy cutting knife, fixed to the door, with optional fixed to machine body
Shear pin design protects pellet mill from damage
Made from high-quality steel material
Computerized control with touch screen
Technical parameters
|
Model |
Capacity(T/h) |
Power (Kw) |
Feeder power(Kw) |
Inner diameter(mm) |
Roller number |
|
HX250 |
0.6-1.0 |
22 |
0.55 |
ᶲ250 |
2 |
|
HX350 |
2.0-6.0 |
30*2 |
0.75 |
ᶲ350 |
2 |
|
HX420 |
6.0-12 |
55*2 |
1.5 |
ᶲ420 |
2 |
|
HX450 |
5.0-12 |
55*2 |
1.5 |
ᶲ450 |
2 |
|
HX600 |
11-16 |
55*2/75*2 |
1.5/2.2 |
ᶲ550 |
3 |
Note: Pellet size: 2.0-12mm
We can offer our strategic partners information inbox.
We have over 320 customers from more than 30 countries in the past 12 years.
