Feed pre-cleaner
Simple structure
Ease to clean and maintain.
Have a aspiration system for assistant cleaning.
Specialized for powdery material cleaning in compound feed mills
SCQZ series fine material conic pre-cleaner is mainly used for pre-cleaning powdery auxiliary materials in compound feed mill. It can effectively break or remove the agglomerated blocks as well as large impurities such as straw, hemp rope, sheet paper, stone block and etc., so as to protect the subsequent machines and equipments in the process system from damage. This machine can also be applied after mixing process to sift and remove the caking bock from mixed mash, so as to ensure the quality of compound feed.
Characteristics
This fine material conic pre-cleaner is characterized by high output, good cleaning effect, low power consumption, simple structure, small floor area and etc.
The equipment is complete with an access door, which is convenient for routine repair and maintenance, as well as for replacement of the sieve drum.
Appropriate sieve apertures can be selected as per the property of material, so as to get the optimum separation effect.
Technical parameters
Model | SCQZ60*50*80A | SCQZ90*80*110A |
Capacity(T/h) | 10-15 | 25-30 |
Power(Kw) | 5.5 | 11 |
